Our Insulation solution deposits silicon nitride using environmentally friendly sputtering technology (PVD) to form a thin non-conductive layer on key electrical components to prevent interference and short-circuit of your devices and improve device’s performance.Get In Touch
|1 ~ 12µm
|600 – 1,200 HV
|0.2 ~ 0.3
|Pencil Hardness Test
|High Temperature Test
|1H @ 150°C
|Salt Spray Test
What are the main advantages of Nanofilm coating?
What kind of coating solutions you provide?
Our coating solutions consist of decorative coating with scratch resistant, tribological wear resistant coating, conductive corrosion resistant coating, non-stick coating, electrical magnetic field insulation, hydrophobic and anti-reflective coating. Click here to find out more.
What are the main applications of your coating?
Our coating solutions resolve mission critical tribological, conductive and surface energy issues for customers in consumer electronics, automotive, semiconductor, hydrogen energy, optical, life science, tool and die and other general industries (textile, printing). Click here to find out more.
What substates can your solutions coat?
We can coat a wide range of substrates including metal (stainless steel, copper, aluminium), alloy, polymer (plastic), and ceramics.
What is the substrate maximum size?
Where are your coating centres?
What is your lead time?
Lead time varies depending on your specification. Please get in touch to learn more.
Do you have any question and want to know more about our services? We will be glad to support you.
